FlexxPump 500 DLS
Continuation sheet
03
EN-
SCHMIERSYSTEME
DIRECT LUBRICATION SYSTEMS
D L S
Nr. Description
0 FlexxPump 500 DLS
1 Lubricant outlet/ outlets (di󰀨erent versions possible)
2 Retaining ring
3 Housing
4 M12x1-electrical interface
5 Nameplate with designation, CE mark and serial number
6 Through hole for assembly
7 Lubricant inlet with thread for cartridge
8 Float
9 Oil cartridge
7
6
Fig. 1: Overview 500 DLS
1
2
0
4
3
5
8
9
