TSC-35/RU User’s Guide
3. Connector
3-1. Explanation of a connector terminal
CN Terminal Name Function
1 UR 5 wire Touch screen UR Input
2 LR 5 wire Touch screen LR Input
3 Sense Coordinate detection
4 UL 5 wire Touch screen UL Input
CN1
5 LL 5 wire Touch screen LL Input
1 Vbus USB Vbus
2 D- USB D-
3 D+ USB D+
4 GND USB GND
CN4*1
5 Shield USB FG
1 Dout RS-232C Data Output
2 Din RS-232C Data Input
CN5
3 GND RS-232C GND
1 Vin Power Input
CN6
2 GND GND
*1: When you use it at 3.3V of the serial mode, please do not connect TSC-35/RU to Vbus of CN4.
3-2. The mounted connector
CN P/N Manufacturer
CN1 RE-H052SD-1110 J.S.T. Mfg Co., Ltd
CN4 S5B-PH-K-S J.S.T. Mfg Co., Ltd
CN5 S3B-PH-K-S J.S.T. Mfg Co., Ltd
CN6 S2B-PH-K-S J.S.T. Mfg Co., Ltd
