Parameter Description Navigation Values
Default
Value
Parameter Description Navigation Values
Default
Value
Positioning
system
Type of positioning system: with Encoder or
traditional. Can only be modified in Temporary Oper.
Mode
Note: in case of absolute Encoder and shaft lengths
longer than 65 meters change the resolution of
Encoder = 2 in autosetting menu before starts the
Manual teach procedure.
◄► (Selection)
FAI/FAS;
Encoder
Clockwise;
Encoder
Counter
clockwise
Absolute
encoder
FAI/FAS
Top PV
Position of the deceleration (passage in Low Speed)
and number of entrances
▲▼
(Increase/Decrease)
2 <-> 6 5
PV at
floors
Position of the specific deceleration for each floor
◄► (Top PV)
▲▼ (Floor choice)
Short floor
or 2<->6
0 <-> No.
Floor
5
all floors
Short level
delay
Time before short level deceleration (only if a short
level is programmed)
▲▼
(Increase/Decrease)
0,00 s <->
2,50 s
0,00s
Top PV 2
Delay
Delay before passage to Intermediate speed
▲▼
(Increase/Decrease)
0,00 s <->
2,50 s
0,00s
Delay Dir.-
BRK
VVVF: Delay between activation of travel direction
and run command (BRK)
▲▼
(Increase/Decrease)
0,0 s <->
3,0 s
0,5 s -
VVVF
0,0 s -
Others
OLEO: Star / Delta delay
▲▼
(Increase/Decrease)
0,0 s <->
3,0 s
0,5 s –
VVVF
0,5 s –
Star/Delta
0,0 s -
Others
Delay
BRK-S
Delay between activation of BRK command and
speed command
▲▼
(Increase/Decrease)
0,0 s <->
3,0 s
0,00 s
Delay
BRK-Dir.
Delay between deactivation of run command and
deactivation of travel direction (arrive al piano)
▲▼
(Increase/Decrease)
0,0 s <->
3,0 s
1,5 s -
VVVF
0,0 s -
Others
Inspection
speed
Sets the speed of travel in inspection ◄► (Selection)
Low
speed;
High
speed
Low
speed
Emergency
BRK On
Emergency break modulation parameter (modify only
if EME board is not present)
▲▼
(Increase/Decrease)
0,0 s <->
5,0 s
0,0s
Emergency
BRK Off
Emergency break modulation parameter (modify only
if EME board is not present)
▲▼
(Increase/Decrease)
0,0 s <->
5,0 s
0,0s
Table of Parameters: (Encoder positioning system):
