D I S P L A Y
11
4,3" / 5"4,3" / 5"4,3" / 5"
Floor N
PRG ADV
FAIL/RUN
12/24 Vdc
NEXT
DIR.
SERIAL
INPUT
LP
LM
4S4S4S
OUT UP
S
OUT DOWN
NEXT DIR.
DK_RS_00M
A
1
3.1.3
Cablaggio ai PIANI con sistema Pitagora DMG
FLOOR wiring with DMG Pitagora system • Branchements PALIERS avec système Pitagora DMG
Anschlüsse ETAGEN mit DMG Pitagora system • Conexiones de PISOS con instalación Pitagora DMG
B
Impostazione display di piano • Floor position indicator setting
PRG
Options
Interface Options
Display Configuration
LIP / LOP
PRG ADV
Programming MENU
C
Impostazione frecce • Arrows setting
PRG
Options
Interface Options
Arrows Configuration
PRG ADV
Programming MENU
PRG ADV
FAIL/RUN
12/24 Vdc
DK_RS_00M
P
IN OUT L-BDU
UP
DOWN
ARROWS OUTPUT
A
2
Direction
Next Direction
Floor N+1
Floor N-1
JST 2p
QVA.CPD__
Floor N-1
Floor N+1
Floor N
V3
QUADRO
CONTROLLER
V4
QUADRO
CONTROLLER
Prossima direzione
Next direction
DK__SS00M
DK__SP00M
