DMG RAFFAELLO Installation Manual

36 pages

To Next Page

To Previous Page

D I S P L A Y

4,3" / 5"4,3" / 5"4,3" / 5"

2.3

RAFFAELLO 5"

A montaggio frontale su piastre 1÷2 mm

Frontal mounted on 1÷2 mm faceplate

143x93 mm - R3,5

Scasso piastra

Faceplate cut-out

Vista FRONTALE

FRONT view
