MONO OPERATION
Depress the Stereo/Mono switch** (LED indicator lit). When operating the
crossover in mono mode, the HIGH-MID/HIGH frequency control range is from
800Hz - 9kHz.
The mono mode setup procedure is the same as for stereo mode, except that
the bottom row of markings on the front and rear panels will be followed
instead of the top row. Be sure that the amplifiers are off, that the gain control
is set to 0 dB, and that the level control is set to -12 before proceeding to
adjust the crossover frequencies and levels. THE LOW FREQUENCY SUM
OUTPUT IS NOT USABLE IN THE MONO MODE.
** WARNING: BEFORE PRESSING THE ÷10, LF SUM OR STEREO/MONO
SWITCHES, LOWER THE OUTPUTS OF YOUR POWER
AMPLIFIERS TO AVOID DAMAGE TO DRIVERS AND
LOUDSPEAKERS.
SR Crossover
5
