CAUTION!
•
When installing the Power Distribution Center
cover, it is important to ensure the cover is prop-
erly positioned and fully latched. Failure to do so
may allow water to get into the Power Distribu-
tion Center, and possibly result in a electrical
system failure.
•
When replacing a blown fuse, it is important to
use only a fuse having the correct amperage
rating. The use of a fuse with a rating other than
indicated may result in a dangerous electrical
system overload. If a properly rated fuse contin-
ues to blow, it indicates a problem in the circuit
that must be corrected.
Front Power Distribution Center Fuses
Cavity Fuse Circuits
1 ——
2 ——
3 15 Amp
Blue
Adjustable Pedals - if equipped
4 20 Amp
Yellow
AC Clutch/Horn
5 ——
6 15 Amp
Blue
Front Control Module (FCM)
7 20 Amp
Yellow
Fog Lights
8 15 Amp
Blue
Lights – License, Park, Side
Marker, Stop, Turn
9 15 Amp
Blue
Front Control Module (FCM)
10 5 Amp
Orange
Powertrain Control Module
(PCM)/Starter
11 20 Amp
Yellow
Auto Shutdown/Powertrain Con-
trol Module (PCM)
12 ——
MAINTAINING YOUR VEHICLE 319
7
