Cavity Fuse Circuits
13 ——
14 25 Amp
Clear
Powertrain Control Module (PCM)
15 25 Amp
Clear
Injectors, Ignition Coils
16 ——
17 30 Amp
Pink
Antilock Brakes System (ABS)
Valves/Powertrain Control Module
(PCM)
18 30 Amp
Pink
Windshield Wiper/Washer
19 50 Amp
Red
Radiator Fan
20 20 Amp
Blue
Starter
21 50 Amp
Red
Antilock Brakes System (ABS)
Pump Motor
22 40 Amp
Green
AC Clutch/Radiator Fan High —
Low
23 ——
Cavity Fuse Circuits
24 60 Amp
Yellow
Radiator Fan - AWD
25 30 Amp
Pink
Front Control Module (FCM)
26 20 Amp
Blue
Transmission - RLE
27 30 Amp
Pink
Front Control Module (FCM)
