WARNING! (Continued)
• If a general protection fuse for safety systems (air
bag system, braking system), power unit systems
(engine system, gearbox system) or steering system
blows, contact an authorized dealer.
Interior Fuses
The interior fuses are located on the drivers side under
the instrument panel.
Cavity Cartridge
Fuse
Mini Fuse Description
F1 – 20 Amp Yellow Front Heated Seats – If Equipped
F2 – 20 Amp Yellow Rear Heated Seats, Heated Steering Wheel – If Equipped
F3 – 10 Amp Red Park Assist Module, Rear Camera, Left and Right Blind
Spot Sensor, Compass – If Equipped
F4 – 15 Amp Blue Instrument Cluster
F5 – 10 Amp Red HVAC, Humidity Sensor, In-Car Temperature Sensor, Inside
Mirror Assembly
F18 – 15 Amp Blue Radio
F19 – 10 Amp Red Fuel Door
596 MAINTAINING YOUR VEHICLE
