Cavity Maxi Fuse Mini Fuse Description
F05 40 Amp Orange – Transmission Control Module #1
F06 30 Amp Green – Body Control Module #3
F07 40 Amp Orange – EBL RLY Coil, Blower Motor RLY Coil
F09 – 5 Amp Tan Radiator Fan
F10 – 10 Amp Red ORC
F11 – 20 Amp Yellow Run/Start, Engine Control Module
F14 – 15 Amp Blue Transmission Control Module #2
F15 – 15 Amp Blue Transmission Control Module #3
F16 – 15 Amp Blue Engine Control Module, Ignition Coils
F17 – 15 Amp Blue Brake System Module
F18 – 20 Amp Yellow Engine Control Module
F19 – 10 Amp Red A/C Compressor Clutch
F20 – 30 Amp Green Rear Defroster (EBL)
F21 – 20 Amp Yellow Fuel Pump
F22 – 10 Amp Red Occupant Restraint Controller
7
MAINTAINING YOUR VEHICLE 599
