Cavity
Cartridge
Fuse
Mini
Fuse
Description
3—
10 Amp
Red
Center High
Mounted Stop Light
(CHMSL)/Brake
Switch
4—
10 Amp
Red
Ignition Switch
5—
20 Amp
Yellow
Trailer Tow – If
Equipped
6—
10 Amp
Red
Power Mirror
Switch/Climate
Controls
7—
30 Amp
Green
Ignition Off Draw
(IOD) Sense 1
8—
30 Amp
Green
Ignition Off Draw
(IOD) Sense 2
Cavity
Cartridge
Fuse
Mini
Fuse
Description
9
40 Amp
Green
Battery Feed – Power
Seats – If Equipped/
PZEV Air Pump – If
Equipped
10 —
20 Amp
Yellow
Instrument Panel/
Power Locks/Interior
Lights
11 —
15 Amp
Lt Blue
Selectable Power
Outlet (Inside Center
Arm Rest)
12 —
20 Amp
Yellow
—
13 —
20 Amp
Yellow
Ignition
14 —
10 Amp
Red
Instrument Panel
446 MAINTAINING YOUR VEHICLE
