Cavity
Cartridge
Fuse
Mini
Fuse
Description
15
40 Amp
Green
— Radiator Fan Relay
16 —
15 Amp
Lt. Blue
Cigar Lighter/
Sunroof – If
Equipped
17 —
10 Amp
Red
Wireless Control
Module (WCM)/
Clock/Steering Con-
trol Module (SCM)
18
40 Amp
Green
—
Auto Shutdown
(ASD) Relay
19 —
20 Amp
Yellow
Audio Amplifier – If
Equipped
20 —
15 Amp
Lt. Blue
Radio
21 —
10 Amp
Red
Siren – If Equipped
Cavity
Cartridge
Fuse
Mini
Fuse
Description
22 —
10 Amp
Red
Ignition Run – Cli-
mate Controls/Hot
Cupholder – If
Equipped
23 —
15 Amp
Lt. Blue
Auto Shutdown
(ASD) Relay 3
24 —
25 Amp
Natural
Sunroof – If
Equipped
25 —
10 Amp
Red
Ignition Run —
Heated Mirrors - If
Equipped
26 —
15 Amp
Lt. Blue
Auto Shutdown
(ASD) Relay 2
7
