FUSES
Interior Fuses
• The interior fuse panel is located on the driver's side under the instrument panel.
Cavity Cartridge Fuse Mini Fuse Description
F1 — 20 Amp Yellow Front Heated Seats
F2 — 20 Amp Yellow
Rear Heated Seats, Heated Steer-
ing Wheel
F3 — 10 Amp Red
PAM, Rear Camera, LBSS, RBSS,
Compass
F4 — 15 Amp Blue IPC
F5 — 10 Amp Red
HVAC, Humidity Sensor, In-Car
Temperature Sensor, Inside Mirror
Assembly
F18 — 15 Amp Blue Radio
F19 — 10 Amp Red Fuel Door
F20 — 10 Amp Red SCCM, SAS, Switch Bank
F21 — 10 Amp Red Diagnostic Port
F22 — 10 Amp Red UGDO, EOM
F23 — 20 Amp Yellow Sunroof
F24 — 5 Amp Tan
Direct Battery For Underhood PDC
(RLY Coils)
F25 — 5 Amp Tan DDCT Feed #4
F26 — 5 Amp Tan Stop Lamp Switch
F27 — 10 Amp Red
Pneumatic Lumbar Support (Sole-
noid), Pneumatic Lumbar Support
(Pump Motor)
MAINTAINING YOUR VEHICLE
111
