Cavity Maxi Fuse Mini Fuse Description
F15 — 15 Amp Blue DDCT Feed #3
F16 — 15 Amp Blue Ignition Coils, Coil Capacitor
F17 — 15 Amp Blue ESC, Brake Pedal Switch, OCM
F18 — 20 Amp Yellow ECM
F19 — 10 Amp Red A/C Compressor Clutch
F20 — 30 Amp Green EBL
F21 — 20 Amp Yellow Fuel Pump
F22 — 10 Amp Red ORC
F23 — 25 Amp Natural ESC
F24 — 20 Amp Yellow ECM, Fuel Injectors, Active Grill
Shutter (AGS)
F30 — 20 Amp Yellow Power Outlet (Console)
F81 60 Amp Blue — Interior PDC Battery Feed, Power
Seats
F82 30 Amp Green — Amplifier
F83 40 Amp Orange — HVAC Blower Motor
F84 — 20 Amp Yellow Run/Accessory RLY Output, Cigar
Lighter
F85 — 10 Amp Red Sunroof, LRSM, Power Outlet
(Console), UCI/AUX Port, Cigar
Lighter
F86 — 20 Amp Yellow —
F87 — 10 Amp Red Wastegate, Purge Solenoid, OBD
Vent Valve, Oxygen Sensor Heat-
ers
F88 — 10 Amp Red Heated Outside Mirrors
