FUSES
WARNING!
•
When replacing a blown fuse, always use an appro-
priate replacement fuse with the same amp rating as
the original fuse. Never replace a fuse with another
fuse of higher amp rating. Never replace a blown
fuse with metal wires or any other material. Failure
to use proper fuses may result in serious personal
injury, fire and/or property damage.
• Before replacing a fuse, make sure that the ignition
is off and that all the other services are switched off
and/or disengaged.
• If the replaced fuse blows again, contact an autho-
rized dealer.
• If a general protection fuse for safety systems (air
bag system, braking system), power unit systems
(engine system, gearbox system) or steering system
blows, contact an authorized dealer.
Interior Fuses
The interior fuses are located on the drivers side under
the instrument panel.
Cavity Cartridge
Fuse
Mini
Fuse
Description
F1 — 20 Amp
Yellow
Front Heated Seats
- If Equipped
F2 — 20 Amp
Yellow
Rear Heated Seats,
Heated Steering
Wheel - If
Equipped
F3 — 10 Amp
Red
Park Assist Mod-
ule, Rear Camera,
Left and Right
Blind Spot Sensor,
Compass - If
Equipped
7
MAINTAINING YOUR VEHICLE 595
