Cavity Cartridge Fuse Micro Fuse Description
F46 10 Amp Red Tire Pressure Monitor - If Equipped
F49 10 Amp Red Integrated Central Stack / Climate Control
F50 20 Amp Yellow Air Suspension Control Module - If Equipped
F51 10 Amp Red Ignition Node Module / Keyless Ignition /
Steering Column Lock
F52 5 Amp Tan Battery Sensor
F53 20 Amp Yellow Trailer Tow – Left Turn/Stop Lights -
If Equipped
F56 15 Amp Blue Additional Content (Diesel engine only)
F57 15 Amp Blue Transmission
F59 10 Amp Red Purging Pump (Diesel engine only)
F60 15 Amp Blue Transmission Control Module
F62 10 Amp Red Air Conditioning Clutch
F63 20 Amp Yellow Ignition Coils (Gas), Urea Heater (Diesel)
F64 25 Amp Natural Fuel Injectors / Powertrain
604 MAINTAINING YOUR VEHICLE
