Right Front Turn Signal
1. Open the hood.
2. Reach behind the headlight unit in the engine com-
partment to access the turn signal bulb.
3. Twist the bulb counterclockwise to remove.
4. Disconnect the electrical connector and replace the
bulb.
Front Side Marker
1. Open the hood.
2. Remove the grille assembly as follows:
a. Remove eight fasteners.
b. Remove two screws from each headlamp.
c. Remove two rivets from the center of the grille.
d. Remove one push pin from the top of each fender.
e. Pull the grille assembly toward you to disconnect
the grille clips to the fender and the headlamp ball-
studs to the front end module.
3. Disconnect electrical connector.
4. Turn the bulb counterclockwise to remove.
Front Fog Lamp (Front Fascia Mounted)
1. Reach under the vehicle to access the back of the front
fog lamp.
2. Disconnect the electrical connector from the front fog
lamp housing.
3. Firmly grasp the bulb by the two latches and squeeze
them together to unlock the bulb from the front fog lamp
housing.
4. Pull the bulb straight out from the keyed opening in
the housing.
7
MAINTAINING YOUR VEHICLE 443
