Cavity Cartridge
Fuse
Mini
Fuse
Description
1 20 Amp
Yellow
Power Outlet Console
2 20 Amp
Yellow
Cabin Compartment
Node (CCN) Door
Locks
3——
4 15 Amp
Blue
Aisin Transmission
Controls (Diesel Only)
5 20 Amp
Yellow
Power Sunroof
6 10 Amp
Red
Vistronic Fan/
Wastegate Solenoid
7——
8 10 Amp
Red
Heated Mirrors
Cavity Cartridge
Fuse
Mini
Fuse
Description
9 30 Amp
Pink
Off Road Module
Power
10 5 Amp
Orange
Trx-Off Rd Pkg Sen
(Gas Engine Only)
NOTE: Insert 5 amp
fuse in this cavity to
enable the TRX capa-
bility (If Equipped).
11 20 Amp
Yellow
Ignition Off Draw
(IOD)-Cabin Com-
partment Node
(CCN)/Radio/Under
Hood Lamp/Wireless
Control Module
(WCM)/Satellite Digi-
tal Audio Receiver
(SDARS)/Hands Free
Module (HFM)/EOM
452 MAINTAINING YOUR VEHICLE
