Cavity Cartridge
Fuse
Mini
Fuse
Description
12 30 Amp
Pink
Electric Brake
13 25 Amp
Natural
Power-Battery
RWAL/ABS Module
Feed
14 15 Amp
Blue
Park Lamps Left
15 20 Amp
Yellow
Trailer Park Lamps
16 15 Amp
Blue
Park Lamps Right
17 — —
18 40 Amp
Green
ABS Pump
19 30 Amp
Pink
Trailer Tow Battery
Feed
Cavity Cartridge
Fuse
Mini
Fuse
Description
20 10 Amp
Red
Occupant Restraints
Controller (ORC) 2
21 10 Amp
Red
Occupant Restraints/
Pass Disable Switch
22 2 Amp
Gray
IGN Switch Feed
23 10 Amp
Red
HVAC
24 20 Amp
Blue
AISIN Relay Feed
(Diesel Only)
25 10 Amp
Red
Power Mirror/T-Case
Brake
26 20 Amp
Yellow
Brake Switch/Center
High Mount Stop
Lamp (CHMSL)/
Aftermarket CHMSL
