108 SERVICING AND MAINTENANCE
F36 40 Amp Green – Mod CBC 2 Exterior Light 1
F37 – – —
F38 – – —
F39 – – —
F40 20 Amp Blue – Dome Pursuit Vehicle
F41A – 15 Amp Blue Lumbar Support & Pass SW / Mod Cluster CCN
F41B – 15 Amp Blue
Mod ICS Switch Bank / Mod HVAC Control / SW Upper
Bank / SW EPB / Ctrl Steering
F42A – 10 Amp Red
Mod TCSM / Mod SBW / SW Electronic Park Brake / Mod
Tire Pressure Trailer (TPM) / Mod Gateway Can-C Trailer
TPM
F42B – 10 Amp Red OHC Switch-E-Call / SW Bank 3 / SW Seat Vent LT & RT
F43A – 10 Amp Red Port Diagnostics / Mod CD / Front & Rear USB
F43B – 10 Amp Red Port Diagnostic 1 & 2
F44 – 20 Amp Yellow Radio / DCSD / Telematics Box Mod
F45 30 Amp Pink – Mod Door MUX Driver
F46 30 Amp Pink – Mod Door MUX Passenger
F47 – – —
Cavity Cartridge Fuse Micro Fuse Description
