112 SERVICING AND MAINTENANCE
Wire Color Chart
INTERIORS
SUEDE STEERING WHEEL CLEANING
It is sufficient to dust the steering wheel using a
soft bristle brush, a dry cloth, or a vacuum
cleaner with care. After having dusted, run a
white cotton terry cloth that has been
dampened and thoroughly wrung out over the
steering wheel.
Avoid the use of printed absorbent cloths/
papers, as they can release ink into the
material. Take extra care not to wet the steering
wheel excessively; rinse the cloth or sponge and
repeat as necessary.
Leave to dry (overnight). Once dried, in order to
restore the material, brush it delicately with a
soft bristle brush.
Circuit Function Fuse Wire Color Location
Aux Switch 1 F601 – 50 Amp Pink/Dark Blue
Underhood (right side near
battery)
Aux Switch 2 F602 – 20 Amp Pink/Dark Green
Underhood (right side near
battery)
Aux Switch 3 F603 – 20 Amp Pink/Violet
Underhood (right side near
battery)
Aux Switch 4 F604 – 50 Amp Pink/Beige
Underhood (right side near
battery)
Aux Switch 5 (If Equipped) F605 – 20 Amp Pink/Brown
Underhood (right side near
battery)
Aux Switch 6 (If Equipped) F607 – 20 Amp Pink/Yellow
Underhood (right side near
battery)
