164
CODE XBE PRE-INSTALLATION REAR WIRING
ELECTRICAL
Chassis cab wiring
prep
Details and Technology
A wiring cable containing seven wires is routed from the auxiliary battery to the rear of the frame. A
switch with indicator light is located in the cab. A ground connection is made from the rear of the frame
to the frame crossmember in front of the rear axle.
Benefits and Arguments
• Simplified retrofitting of body upfits
Remarks
Pre-installation Rear Wiring (XBE) requires the 100-amp Auxiliary Battery (BC1).
