PRE-INSTALLATION

LOAD COMPARTMENT WIRING

ELECTRICAL

Electrical

pre-installation for

load compartment

lighting

Details and Technology

A two-strand wiring harness is installed which extends approximately .9 metres (three feet) aft of the cab

rear wall, with a switch on the instrument panel.

Benefits and Arguments

• Simplifies retrofitting of load-compartment lighting

Allows body manufacturers for chassis cab to fit load compartment lighting quickly and easily.
