CAUTION!
Failure to follow these procedures could result in
damage to the charging system of the booster vehicle
or the discharged vehicle.
6. Connect the positive (+) end of the jumper cable to the
remote positive (+) post of the discharged vehicle.
7. Connect the opposite end of the positive (+) jumper
cable to the positive (+) post of the booster battery.
8. Connect the negative (-) end of the jumper cable to the
negative (-) post of the booster battery.
9. Connect the opposite end of the negative (-) jumper
cable to the remote negative (-) post of the vehicle with
the discharged battery.
Remote Jump Start Connections
1 — Remote Positive (+) Post
2 — Remote Negative (-) Post
6
WHAT TO DO IN EMERGENCIES 331
