Power Distribution Center
The Power Distribution Center is located in the engine
compartment on the driver’s side of the vehicle. This
center contains fuses and relays.
Cavity Relay Cartridge Fuse Mini-Fuse Description
3 — 40 Amp Green — Rad Fan
4 — 40 Amp Green — Rad Fan Rly High
5 — 40 Amp Green — ABS/ESP Pump Feed
6 — 40 Amp Green — Starter
Power Distribution Center
372 MAINTAINING YOUR VEHICLE
