Cavity Relay Cartridge Fuse Mini-Fuse Description
7 — 40 Amp Green — CBC (Ext. Lighting #1)
8 — 40 Amp Green — CBC (Ext. Lighting #2)
9 — 30 Amp Pink — CBC (Lighting, Washer Pump)
10 — 30 Amp Pink — CBC (Power Lock)
11 — Jumper Black — B+ Jumper
12 — 25 Amp Clear — ABS/ESP Valve Feed
13 — — 20 Amp
Yellow
Horn
14 — — 10 Amp Red A/C Clutch
15 — — 10 Amp Red Diagnostic, Fuel Door, Stop Switch
16 — — 15 Amp Blue KIN, RF Hub
17 — — 25 Amp cir-
cuit breaker
Power Seats
18 — 30 Amp Pink — Driver Door Mod
19 — 30 Amp Pink — Passenger Door Mod
7
