Cavity Relay Cartridge Fuse Mini-Fuse Description
20 — 30 Amp Pink — Rear Window Defroster
21 — 20 Amp Blue — Wiper
22 — Jumper Black — B+ Jumper
23 — — 15 Amp Blue HVAC MOD, Cluster, ICS-Switch Bank
24 — — 25 Amp
Clear
PCM-Powertrain Control Module
25 — — 25 Amp
Clear
Fuel Pump
26 — — 20 Amp
Yellow
ASD #1
27 — — 20 Amp
Yellow
ASD #2
28 — — — Spare
29 — 40 Amp Green — HVAC Blower
30 — 20 Amp Yellow — RR Power Outlet, Adj. Pedals, UCI
