Name: DOEPFER A-100 DIY Kit 1
Brand: DOEPFER
Rating: 4 (1 reviews)

To Next Page

To Previous Page

external Transformer

15V AC / 2.5A

15V AC

DIY Netzteilplatine

DIY Power Supply Board

Busplatine 1

Bus Board #1

Busplatine 2

Bus Board #2

Gehäuseanschluss (nur bei Metallgehäuse)

housing (only if a metal case is used)

hier kann eine 2-polige Steckverbindung eingefügt werden,

die für 2,5A zugelassen ist (z.B. XLR)

here a 2-pin connector can be inserted

that is suitable for 2.5A (e.g. XLR)

mains

rot/red = +12V

schwarz/black = GND

blau/blue = -12V

Verdrahtung von A-100 DIY Kit #1

Wiring of A-100 DIY kit #1

Sicherung max. 2,5A

fuse max. 2.5A
