DOEPFER A-100 - Page 35

doepfer
System A - 100 8. Module overview
29
Module Width Curr. Curr.@5V Description
A-182
6- -
Switched Multiple
eight sockets that can be switched to one of two busses or turned off
A-185-1
430 -
Bus Access Module
module for access to bus signals CV and gate
A-185-2
610 -
Precision Adder / Bus Access
high precision CV adder (0,1%) with 4 inputs and optional access to bus CV
A-186
4- -
Gate / Trigger Combiner
7 inputs that are "OR-wired" to the output, mainly for combination of gate/trigger signals
A-187-1
18 200 -
Digital Effects Module
DSP effects module with 4 voltage controller parameters
A-188-1
14 80 -
BBD Module
BBD module available with 6 different BBD types (128/256/512/1024/2048/4096 steps)
A-188-2
30 120 -
Tapped BBD Module
BBD module with 6 taps, single outputs and two (stereo) submixers
A-189-1
850 -
VC Bit Modifier
Bit modifier with 16 different algorithms (incl. But Crunching)
A-190-1
10 10
•
/ 50
MIDI-CV/SYNC-Interface
(module no longer available)
MIDI-to-CV and sync interface
A-190-2
650
-
MIDI-CV/Gate-Interface
MIDI-to-CV and gate interface, 4 CV outputs, Glide Control for CV1
A-190-3
660
-
MIDI/USB-CV/Gate-Interface
MIDI/USB-to-CV and gate interface, 4 CV outputs, Glide Control for CV1
A-190-4
10 200
-
MIDI/USB-CV/Gate/SYNC-Interface
MIDI/USB-to-CV/Gate/sync interface
A-190-5
?? -
Polyphonic Midi/USB-CV/Gate-Interface
(still under development)
4 x 3 CV outputs, 4 Gate outputs, different modes and assign algorithms
A-190-8
650
-
MIDI/USB-SYNC-Interface
MIDI/USB-to-Sync interface with several clock outputs, start/stop/reset, wait function
