8. Module Overview System A - 100
doepfer
28
Module Width Curr. Curr.@5V Description
A-170
820 -
Dual Slew Limiter
two independent portamento controllers or integrators
A-171-1
820 -
VC Slew Limiter
voltage controlled portamento controller/integrator
A-171-2
830 -
VC Slew Limiter / Processor / Generator
licence copy of the SERGE VC Slew Limiter
A-172
410 -
Maximum/Minimum Selector
selects from up to 4 analog inputs the maximum and minimum voltage
A-174-1
10 40 -
Joy Stick
module with 2 separate CV outputs controlled by the X/Y position of the joy stick
A-174-2
14 10 -
Dual Wheel Module
2 modulations wheels with CV outputs
A-175
420 -
Dual Voltage Inverter
two independent analog voltage inverter with displays
A-176
820 -
CVS - Control Voltage Source
3 manual adjustable control voltages
A-177
830 -
External Foot Controller
(module no longer available)
interface module for 2 foot pedals and double foot switch
A-177-2
410 -
External Foot Controller
interface module for 2 foot pedals and double foot switch
A-178
860 -
Theremin Control Voltage Source
variable voltage/gate source controlled by hand movement
A-179
860 -
Light Controled Voltage Source
(module no longer available)
variable voltage/gate source controlled by light intensity
A-180-1
4- -
Multiples 4HP
8-fold multi connector (may be splitted into two 4-fold multi connectors)
A-180-2
2- -
Multiples 2HP
8-fold multi connector (may be splitted into two 4-fold multi connectors)
A-181
4- -
Multiples 2
two multiples with 3.5 mm and 1/4“ mono and stereo sockets
