Dolmar HT-2145 D - Carburetor Assembly Details; Air Filter System; Primer Pump and Fittings; Cable Adjustment and Mounting

Page
Pos.
HT-2145 D
HT-2162 E
Part No. Notes Description Specifications
6 111 1 374 650 120 GASKET
6 112 1 381 600 801 CABLE ADJUST SCREW
6 113 1 377 270 600 NUT M6
6 114 1 374 650 010 CABLE BRACKET
6 115 1 381 350 280 SPACER GASKET
6 116 1 381 601 200 CARBURETOR INC. 117-119,121-132
6 117 1 381 600 512 RING
6 118 1 381 601 804 SWIVEL
6 119 2 388 600 803 PAN HEAD SCREW
6 120 1 388 950 000 HOLDER
6 121 1 381 600 101 O RING
6 122 1 367 602 402 JET
6 123 1 381 600 103 PUMP GASKET
6 124 1 381 600 104 PUMP DIAPHRAGM
6 125 1 381 600 401 INLET SCREEN
6 126 1 374 604 613 PUMP BODY ASS'Y
6 127 1 381 604 604 METERING DIAPHRAGM GASKET
6 128 1 381 600 525 METERING DIAPHRAGM ASS'Y
6 130 1 381 600 115 PRIMER PUMP
6 131 1 374 604 605 PRIMER PUMP COVER
6 132 4 381 604 601 PUMP COVER SCREW
6 133 1 374 606 100 O RING
6 134 1 374 300 402 AIR CLEANER HOUSING
6 135 1 374 300 401 AIR FILTER
6 136 1 374 300 403 AIR CLEANER COVER
6 137 2 367 330 560 SCREW ASS'Y M5X60(W/W)
6 * A01 1 377 900 100 STANDARD EQUIPMENT TOOL KIT
* NO PICT.
HT-2162 E
