CT100G Series Inverter CHAPTER 4 FUNCTION PARAMETER TABLE
- 58 -
Functio
n code
Name Detailed instruction of parameters
Default
value
Attrib
ution
A02.36
Integral gain of M axis 0
～
60000
1300 ○
A02.37
Proportional gain of T axis 0
～
60000
2000 ○
A02.38
Integral gain of T axis 0
～
60000
1300 ○
A02.39
Integral attribute of speed loop
Unit place:integral separation
0: Integral always valid
1: speed loop integral separation
0 ○
A02.40
Synchronous motor weak
magnetic mode selection
0:no weak magnetic
1:direct calculate
2:Automatic adjust
0 ○
A02.41
Over modulation enable
0:forbid
0 ○
A02.42
Maximum output voltage
coefficient
100%
～
110%
105 ☆
A02.43
Maximum torque coefficient in
weak magnetic region
50%
～
200%
100 ○
A02.44
Selection of generation
(braking) torque enabling under
speed model
0:disable
1:enable
0 ○
A02.45
Motor control mode
0:sensorless vector control (SVC)
1:vector control with sensor (FVC)
2:V/F control
2 ☆
A02.46 ACC time / DEC time selection
0: same as motor 1
1: ACC time / DEC time 1
2: ACC time / DEC time 2
3: ACC time / DEC time 3
4: ACC time / DEC time 4
0 ○
A02.47 Motor torque magnify
0.0%: automatic torque magnify
0.1%~30.0%
1.0 ○
A02.48 reserve reserve 0 ●
A02.49 Oscillation suppression gain 0~100 0 ○
A05.00
DPWM switch high limit
frequency
5.00Hz
～
max frequencyF00.06
8.00 ○
A05.01
PWM modulate mode
0:Asynchronous modulate
1:Synchronous modulate
0 ○
A05.02
Dead zone compensation
mode selection
0:no compensation
1:compensation mode 1
2:compensation mode 2
1 ○
A05.03
Random PWM
0:not choose
1
～
10: random depth selection
0 ○
A05.04
Cycle by cycle current limiting
enabling
0:not enable
1: enable
1 ○
A05.05
Current detection delay
compensation
0
～
100
5 ○
A05.06
Under voltage point setting
200.0v
～
2000.0v set by model
220v:200v
380v:350v
480v:350v
350.0 ○
