CT100G Series Inverter CHAPTER 1 PRODUCT INFORMATION
- 5 -
CHAPTER 1 PRODUCT INFORMATION
1.1 Product model name rules
The letters and numbers of the type designation key indicate product
series, voltage, power, load etc.
Figure 1-1 Type designation key
1.2 Product specifications and technical parameters
1.2.1 Product specifications
Table 1-1 Product Specifications
Inverter mode
Power
（KW）
Input
current
（A）
Output
current
（A）
Applicable
motor power
（KW）
Single phase 220V 50/60Hz
CT100G-2S-0.7G-B 0.75 8.2 4.5 0.75
CT100G-2S-1.5G-B 1.5 14.0 7.0 1.5
CT100G-2S-2.2G-B 2.2 23.0 9.6 2.2
CT100G-2S-4.0G-B 4.0 36.0 16.0 4.0
CT100G-2S-5.5G-B 5.5 46.0 20.0 5.5
CT100G-2S-7.5G-B 7.5 68.0 30.0 7.5
Three phase 380V 50/60Hz
CT100G-4T-0.7G-B 0.75 3.4 2.5 0.75
CT100G-4T-1.5G-B 1.5 5.0 3.7 1.5
CT100G-4T-2.2G-B 2.2 5.8 5.3 2.2
CT100G-4T-4.0G-B 4.0 12.0 9.5 4.0
