Dometic 4300 Series Installation Manual

5
Dometic 4300/4400 Series Toilets Specifications
4.3 Dimensions
(g.
2
, p. 2) All dimensions may vary ±3/8 inch (10 mm)
4.2 Minimum System Requirements
Electrical
Circuit breaker 2 amps/12 V DC
Wiring 14 gauge stranded copper
Water
Supply
Fitting 0.5 in. NPT
Flow rate 4 gpm/15 lpm minimum at toilet
Maximum ow pressure 40 PSI / 276 kPa
Discharge Fitting
4-bolt oor (closet) ange. 3-in. (76 mm) ID
ABS or PVC connection to holding tank
Specications are subject to change without notice.
4 Specifications
4.1 Materials
Toilet: vitreous ceramic
Dometic switch panel (4300 series): polycarbonate resin
Flush handle (4400 series): plated brass
Ref. Dimension
A 19 in. / 483 mm
B 14.75 in. / 375 mm
C 21.5 in. / 546 mm *
D 17.75 in. / 451 mm - seat height
E 17.125 in. / 435 mm *
F 11 in. / 279 mm - centerline
rough-in *
G 33.75 in. / 857 mm - seat lid up
Ref. Dimension
A 19 in. / 483 mm
B 15.875 in. / 403 mm
C 21.5 in. / 546 mm *
D 17.75 in. / 451 mm - seat height
E 17.125 in. / 435 mm *
F 11 in. / 279 mm - centerline
rough-in *
G 33.75 in. / 857 mm - seat lid up
Models with wall-mounted flush
switch
Models with flush handle
* For toilet models with hand sprayer, add 0.25 in. / 6.3 mm to dimensions C, E, F to allow small space
between toilet and wall.
