Dometic 4310 User Manual

13
EN
Full Ceramic Gravity Discharge Toilet Troubleshooting
14. Pull the mounting bracket and the rotor cam off the
base.
15. Rotate the flush ball forward and remove the flush-
ball retaining screw.
16. Replace the flush ball.
17. Reverse the disassembly procedure. Before
reassembling the entire toilet:
– Push the rotor cam all the way onto the rotor sha
and tighten the set screw.
– Lubricate the moving parts with silicone grease.
– Check the cam switch for adjustment. See "7.1
Aligning the Cam Switch/Flush Ball" on page 11.
7.5 Replacing the Rotor Sha
Follow this procedure to replace the rotor sha:
1. Follow the disassembly steps in "7.4 Replacing the
Flush Ball" on page 12.
2. Pull the rotor sha out from inside the base.
3. Lubricate the O-rings on the new sha using silicone
grease.
4. Align the flat section on the rotor sha with the flat
section in the cam.
5. Push the rotor sha cam fully onto the rotor-sha.
Tighten the set screw.
6. Lubricate all moving parts using silicone grease.
7. Reverse the disassembly procedure. Before
attaching the base to the toilet, check the cam switch
for adjustment. See "7.1 Aligning the Cam Switch/
Flush Ball" on page 11.
7.6 Replacing the Rotor Sha Cam
Follow this procedure to replace the rotor sha cam:
1. Follow disassembly steps under "7.4 Replacing the
Flush Ball" on page 12.
2. Remove the linkage pin clip and pin.
3. Attach the new rotor sha cam to the linkage, using
the pin and clip.
4. Lubricate all moving parts using silicone grease.
5. Reverse the disassembly procedure.
6. Reverse the disassembly procedure. Before
attaching the base to the toilet, check the cam switch
for adjustment. See "7.1 Aligning the Cam Switch/
Flush Ball" on page 11.
7.7 Replacing the Motor Drive Arm
Follow this procedure to replace the motor drive arm:
1. Follow the disassembly steps in "7.4 Replacing the
Flush Ball" on page 12.
2. Remove the four motor-mounting screws.
3. Remove the motor from the mounting bracket.
4. Loosen the drive-arm set screw using a 3/32 in.
(0.25 mm) hex tool.
5. Remove the old drive-arm.
6. Install the new drive arm and push it on the motor
sha as far as possible.
7. Tighten the set screw.
8. Lubricate all moving parts using silicone grease.
9. Reverse the disassembly procedure. Before
attaching the base to the toilet, check the cam switch
for adjustment. See "7.1 Aligning the Cam Switch/
Flush Ball" on page 11.
7.8 Replacing the Drive Linkage
Follow this procedure to replace the drive linkage:
1. Follow the disassembly steps in "7.4 Replacing the
Flush Ball" on page 12.
2. Remove the linkage pin clip and pin at the rotor sha
cam.
3. Remove the flush spring retaining screw and washer
from the retaining post.
4. Remove the flush spring from the old linkage.
5. Insert the flush spring to the new linkage
6. Reattach the spring to the retaining post.
