RM(x)8xx6 Installing the refrigerator
21
5.4 Installing the ventilation grill
➤ Proceed as shown (fig. f, page 6 to fig. h, page 6).
5.5 Install the roof vent
➤ Proceed as shown (fig. j, page 7 to fig. k, page 7).
5.6 Installing the flue duct
I
The flue duct is installed at the factory. Proceed as follows when you have removed
the flue duct and want to reinstall it (fig. l, page 7):
➤ Place the T-piece (1) onto the flue pipe (2).
➤ Direct the T-piece at an angle of 45° towards the rear wall.
➤ Attach the T-piece and flue pipe with a screw (3).
No. in
fig. e, page 5
Description
1 Installation frame
2 Ventilation grille
3 Winter cover
4Slider
No. in
fig. i, page 6
Description
1 Installation frame
2 Hood
NOTE
Do not install an additional flue stack, as this leads to poor performance
and increases the power consumption of the refrigerator.
