Installation Dometic BR342
12 EN
5.5 Placing the unit on rooftop
➤ Remove unit from carton and discard the carton.
CAUTION! Lifting hazard
Use proper lifting technique and control when lifting product. The rooftop unit weighs approximately 35 kg.
Follow occupational health of safety guide when lifting or moving the unit. Failure to obey this caution could result
in injury.
NOTICE! Beware of damage
Do NOT slide unit. Otherwise, damage to gasket (on bottom of unit) may occur, and could cause a leak.
➤ Lift and place the unit over the prepared opening using the gasket on the unit as a guide.
➤ Place the ADB kit inside the RV. This contains mounting hardware for the unit and will be used inside the vehicle.
