CONNECTING POWER TO THE FAN
1. Remove the temporary tape holding the black fan wire in place.
2. Locate the fan power plug below the USB port.
3. Routing the black fan wire away from the fan blades, connect it to the fan
power plug.
4. Gently push the connected fan wires back into the opening, protecting
the wires from the fan blades.
5. Start the vehicle engine.
6. Press and hold the ON/OFF button for one second to turn the
refrigerator unit on and to listen for the condenser fan to start. See
“Troubleshooting” if the condenser fan does not start.
7. Press and hold the ON/OFF button for one second to turn the
refrigerator unit OFF.
8. Turn the vehicle engine OFF.
Front Fan
Fan Power Plug
Black Fan Wire
9. At the front edge of the refrigerator unit, ensure the twist lock horizontal
tabs fit underneath the front lip of the console bin.
10. Using a Phillips screwdriver, turn each twist lock clockwise until the
horizontal tabs are snug against the console bin.
Twist Locks (2)
