8
Roof chimney Truma, art.No. 30700-03
atr. No. 39320-00
Ventilation chimney tube Truma O55
Exhaust box
Figure 4
Installation of oven with exhaust of waste gases upward through a chimney across the wall.
Chimney across the wall Truma, art.No. 34011-08
Ventilation chimney tube Truma O55
atr. No. 39320-00
Exhaust box
Figure 5
Installation of oven without a chimney exhausting waste gases through front of appliance.
