7
Minimum distance from inflammable surfaces on the right and left sides: 20 mm. Minimum
distance from inflammable upper surfaces: 50 mm. Minimum distance of the waste gas
exhaust case from inflammable surfaces: 50 mm.
All walls or constituent parts that are at a smaller than minimum distance from the appliance
should be either lined or protected with non-flammable materials.
Figure 2
Figure 3
Installation of oven with gas exhaust pipe upward through roof chimney.
