10
Figure 6
Installation of oven with gas exhaust pipe at the back through roof chimney.
Ventilation chimney tube Truma O55
Roof chimney Truma, art.No. 30700-03
atr. No. 39320-00
Exhaust box
Figure 7
Installation of oven with exhaust of waste gases at the back through a chimney across the wall.
Chimney across the wall Truma, art.No. 34011-08
Ventilation chimney tube Truma O55
atr. No. 39320-00
Exhaust box
