CRX Installing and connecting the refrigerator

6.2 Control elements

7 Installing and connecting the

refrigerator

7.1 Safety instructions for installation on boats

Please note the following instructions for installation on boats:

4Shelf

5 Fruit compartment

6 Bottle restraint

(to hold bottles in the door)

7 Compartment with lid (hinged)

No. in

fig. 6, page 4,

fig. 7, page 5

Explanation

1 IR sensor for switching the interior light

2 LED Service display

3 LED Blue: Compressor is running

LED Orange: Compressor is off

4 On/off button

5 Inner lighting

6 Temperature selection button

7 LED: Fast cooling function on (CRX50, CRX65, CRX80)

LED: Winter mode on (CRX110ACDC, CRX140ACDC)

8 LEDs: Temperature levels

DANGER!

If the appliance is powered by the mains, ensure that the voltage supply

has a residual current circuit breaker.

No. Explanation
