Dometic CU401 - Figure 4: Installation Clearance Diagram

FIGURES AND
TECHNICAL DRAWINGS
20
IT
EN
200 mm
200 mm
600 mm
100 mm
Figure 4
CU311 - CU311M - CU333 - CU333M
- CU335 - CU335M - CU401 -
CU401PE - CU402 - CU402PE
- CU403 - CU403PE - MO8103 -
MO8123 - PI0913 - PI0913A - PI8002
- PI8022 - PI8003 - PI8023 - PI8403 -
PI8403GL - PI8423 - PI8423GL - PI8443
- PI8463 - PI8621A - PI8621S - PI8621R
100 mm
170 mm
FO311 - VN555
