Installing the device CVH1525(G), CVC1700G
22
Observe the following instructions for the connection:
• Observe the national requirements.
• The device is not suitable for connection with a hose pipe.
Only use a steel pipe Ø 8 x 1 mm (welded, seamless steel or stainless steel) for the
connection.
• Fasten the gas line to the side or rear wall of the surrounding furniture parts so that
no loads are placed on the actuators.
• The entire gas line must be free of stress.
• The supply connection point shall be accessible with the device installed.
1. Connect the pipes as shown (fig. 8, page 7).
2. Attach a sign above the device with the following text:
“WARNING!
When cooking, additional ventilation must be provided, for example, by
opening windows near the device.
The device must not be used as a space heater.”
3. Open the gas supply.
!
4. Check all connections for leaks with soapy water.
✔ There are no leaks if no bubbles form.
7.4 Connecting the device to the 12 V DC power supply
The following only applies to models with electronic ignition.
1. Connect the device as shown (fig. 9, page 8).
2. Add a 1 A fuse in the plus line near the battery.
WARNING! Explosion hazard
Never check for leaks with an open flame or near sources of ignition.
