Microwave
2 GENERAL INFORMATION
This section provides the list the parts that are included with the Dometic Model DCMC11B.F Convection
Microwave Oven and describes the tools that are recommended for installation of the unit.
I
The installation package does not include the installation cabinet. See "Pre-Installation" on page 8 of
this manual for cabinet specifications.
Included Parts Quantity
Convection Microwave Oven 1
Trim Frame 1
Rear Air Baffle 1
Top Air Baffle 1
Upper Exhaust Guide 1
Lower Exhaust Hood 1
#5 x 1.0 in. (25.0 mm) Screw 6
#8 x 5/16 in. (8.0 mm) Screw 11
#8 x 13/32 in. (10.0 mm) Screw 4
Recommended Tools and Hardware
Electric Drill
Phillips Head Screwdriver
Straight Edge or Square
