INSTALLATION
Wiring Diagrams
FIG.1
Sail Switch
N.O.
Red
(12 VDC)
PWR
BLO
Blue
Limit Switch N.C.
Blue
Valve
Ignition
Control
Blue
Blue
On/Off Switch-
Breaker
Blue Blue + Thermostat
Thermostat
Red + 12 VDC
– 12 VDC
Red
Red
Electrode
Red
Red
Motor
Black
Black
Black
Black
Black
(12 VDC)
FIG.2
Valve
Motor
Sail Switch
Thermostat
Switch/Breaker
12 Volts DC
Electrode
Limit Switch N.C.
GND
BLO
TH
V1
HV
AIR
PWR
Ignition
Control
4
4
1
5
2
1
3
2
FIG.3
Sail Switch
N.O.
(120 VAC)
Limit Switch N.C.
On/Off
Switch
Valve
Ignition
Control
Blue
Black
Green
Blue
White
Thermostat Thermostat
120VAC Hot
120VAC Neutral
Ground
Electrode
Motor
4-Pin
Gnd
Transformer
Brown White
White
Green
Red
Red
Blue
Blue
Blue
Blue
Black
Black
Green
Green
Capacitor
Yellow
1
IND
L1
R
24V
(120 VAC)
FIG.4
Valve
Electrode
Motor
Green
White
Black
Capacitor
Thermostat
Transformer
Sail Switch
Limit Switch
GND
Power
Switch
Ignition
Control
HV
PS TH R L1
V1
IND24V
12
3
3
2
4
1
