GENERAL INFORMATION
DFLD35, DFLD40, DFLA35, DFLA40 (Large Furnace Models)
MODELS
DFLD35 DFLD40 DFLA35 DFLA40
TYPE OF GAS
LP Gas LP Gas LP Gas & Natural Gas LP Gas & Natural Gas
BTU INPUT
35,000 40,000 35,000 40,000
BTU OUTPUT
26,600 30,400 26,600 30,400
DUCT STATIC PRESSURE
0.10" WC 0.10" WC 0.10" WC 0.10" WC
AMPERAGE (AMPS)
12.5** 12.5** 2.5* 2.5*
WATTS
138 138 300 300
POWER SUPPLY
12 VDC 12 VDC 120 VAC 120 VAC
RETURN AIR
80 in.
2
80 in.
2
80 in.
2
80 in.
2
MINIMUM RETURN AIR
65 in.
2
65 in.
2
65 in.
2
65 in.
2
WC = Water Column; *15 Amp dedicated circuit for Furnace; **20 Amp dedicated circuit for Furnace
B. Model Dimensions
DFSAD12, DFSD12, DFSD16, DFSD20 (Small Furnace Models)
COMPONENT WIDTH HEIGHT DEPTH WEIGHT
Casing 12" 7" 20"
Furnace 21 lbs.
Boxed 24 lbs.
Small Vent 4-7/16" 4-7/16" 1-1/16"
Door 14-3/4" 9-3/4" 1/2"
Interior Grill 8-1/2" 12-1/2" 1/2"
Trim Ring 14-1/8" 10-1/8" 1/8"
DFMD16,DFMD20, DFMD25, DFMD30, DFMD35 (Medium Furnace Models)
COMPONENT WIDTH HEIGHT DEPTH WEIGHT
Casing 16-1/2" 7" 20"
Furnace 26 lbs.
Boxed 29 lbs.
STD Door 19-1/16" 9-1/2" 7/16"
Flush Door 20-5/8" 11" 7/32"
Small Vent 4-7/16" 4-7/16" 1-1/16"
DFLD35, DFLD40, DFLA35, DFLA40 (Large Furnace Models)
COMPONENT WIDTH HEIGHT DEPTH WEIGHT
Casing 16-1/2" 9" 20"
Furnace 39 lbs.
Boxed 46 lbs.
Door 19-1/4" 9-1/4" 1/4"
Recess Bezel 20-9/16" 11-1/2" 3/8"
Small Vent 4-7/16" 4-7/16" 1-1/16"

Dometic DFSD12 Specifications

General

Brand	Dometic
Model	DFSD12
Category	Furnace
Language	English
