Installation DM50C
14
6.2 Mounting the minibar into a piece of furniture
➤ Fasten the minibar with the four screws ø4 x 45 mm (1).
➤ Insert the four plugs (2) into the boring.
6.3 Connecting the minibar electrically
➤ Connect the 230 V connection cable to the 230 V AC mains supply.
✓ The status LED lights up.
✓ The minibar starts cooling the interior.
6.4 Mounting hotel's own door decor (DM50CF only)
The hotel's own door decor has to comply with the following requirements:
• Maximum weight: 2 kg
• Maximum thickness: 14 mm
➤ Fasten the decor with four screws.
Mounting the lock (lock version only)
➤ Drill a hole with a diameter of 35 mm into the decor.
➤ Mount the lock together with the lock decor.
Item Description
1Screw ø4x45mm
2Plug
2
1
DM50C-MB--AUS--EN.book Seite 14 Donnerstag, 1. September 2016 9:08 21
