Service codes DSP-EM
8
Service code Description Range
Stand
ard
value
Device
S-22 Generator mode Switches the generator mode of the
DSP-C inverter ON/OFF.
ON, OFF ON DSP-C
S-23 UPS function Switches the uninterrupted power
supply ON/OFF.
ON, OFF OFF DSP-T, DSP-C
S-24 UPS timer Sets the duration in which the inverter
supplies the end device with power if
the inverter is no longer supplied with
AC power.
OFF, 0.5 min to 30 min
in 0.5 min intervals
OFF DSP-T, DSP-C
S-25 AC high-voltage
shutdown
Sets the upper voltage value at which
the inverter switches off.
250Vto280V
in 2 V intervals
270 V DSP-C
S-26 Upper AC restart
voltage
Sets the voltage at which the inverter
switches on again after a high-voltage
shutdown.
no recovery,
220Vto278V
in 2 V intervals
250 V DSP-C
S-27 AC low voltage
shutdown
Sets the lower voltage value at which the
inverter switches off.
180V to 210V
in 2 V intervals
180 V DSP-C
S-28 lower AC restart
voltage
Sets the voltage at which the inverter
switches on again after a low-voltage
shutdown.
no recovery,
182Vto240V
in 2 V intervals
220 V DSP-C
S-29 Program version
number
– Program version number – DSP-C
S-30 Battery charging
status switch off
Sets the battery charging status at which
the inverter switches off.
OFF, 10 % to 60 %
in 5 % intervals
OFF IBS and IBS
multiplexer
S-31 Charging status
advance warning
sensitivity
Sets the percentage from which an
imminent switch off is displayed.
5% to 15%
in 5 % intervals
10 % IBS and IBS
multiplexer
S-32 Standby timer display Sets the time after which the display
switches to standby mode if no entries
are made.
OFF, 1 min to 10 min
in 1 min intervals
1min Display
S-33 Display self-test All symbols illuminate. ON/OFF OFF Display
S-34 Display program ver-
sion number
Program version number – – Display
S-35 Factory settings Resets the settings back to the standard
values.
ON/OFF OFF DSP-T, DSP-C
