Installation FreshJet3000
18
See fig. f, page 7
8.5.3 Mains cable
➤ Connect the roof air conditioner with the mains voltage supply.
Connect the cables (1) to a cable connector (2).
8.5.4 Communication cable
➤ Pull out the filter slightly to create a gap for the communication cable (3).
➤ Feed the communication cable through the gap and locate the wire in the
opening.
See fig. g, page 8
➤ Stack the duct sections and place against the roof thickness: the duct height
should match the roof height. Or use the below table as a guide:
9Fan condenser
10 Out air sensor
11 Evaporator sensor
12 Condenser sensor
13 Discharge sensor
14 Inductor
ye yellow
bn brown
bu blue
gn green
vt violet
rd red
wh white
bk black
Roof thickness Number of duct sections
18 – 28 mm 1
28 – 38 mm 2
38 – 48 mm 3
48 – 58 mm 4
58 – 68 mm 5
Item (fig. e,
page 7)
Description
FreshJet3000--INM.book Seite 18 Donnerstag, 12. März 2020 11:39 11
